The Heartway S12X Vita
Monster is a sleek, all-terrain power scooter. The
Vita Monster has a 900-watt motor and uses a 200 Amp
S-drive controller to power through all types of
terrain. The 15″ x 6.3″ rear turf tires allow easy
outdoor maneuverability.
The Vita Monster has a
double A-Arm front suspension and 3D rear suspension
for a smooth ride and maximum shock absorption. It
comes with a full LED light package, rearview mirrors,
and a roll bar.
The Vita Monsters top
speed is 11.5 mph, with a range of up to 28 miles per
charge. Other features for the Vita Monster include a
sporty 20″ captains seat, cup holder, and adjustable
tiller.
The Heartway S12X Vita Monster is a high-performance,
all-terrain mobility scooter designed for users
seeking power, durability, and comfort across various
terrains.
Key Features
Motor & Controller: Equipped with a robust 900-watt motor
and a 200 Amp S-drive controller, the Vita Monster
delivers exceptional power and control, making it suitable
for diverse terrains .
Speed & Range: Achieves a top speed of up to 11.5 mph and
offers a travel range of up to 28 miles on a single
charge, thanks to its dual 12V 75Ah batteries .
Suspension System: Features a double A-arm front
suspension and 3D rear suspension, ensuring a smooth and
comfortable ride over uneven surfaces .
Tires: Fitted with large 15″ x 6.3″ rear turf tires and
13″ x 4″ front street tires, providing excellent traction
and stability on various terrains.
Overall Length
64″ in / 162 cm
Overall Width
31″ in / 79 cm
Overall Height (at Maximum
Tiller Height)
54″ in / 136 cm
Overall Height at Minimum
Tiller Height
46″ in /117 cm
Legroom Floorboard Length x
Width
13″ in / 132 cm
Deck Height Floorboard to
Floor
9.4″ in /24 cm
Ground Clearance
4″ in / 10 cm
Turning Radius
53″ in / 135 cms
Weight with Std.
330 lbs / 150 kgs
Weight without Batteries
220 lbs / 100 kgs
Seat Type
Captain Seat
Seat Width & Depth & Height
20″ in / 50 mm x 19″ in / 48
cm x
30″ in / 75 cm
Seat Cushion Thickness
6″ in /15cm
Seat Height Cushion to Deck
19.7″ in /50 cm
Seat Height Cushion to Floor
29.5″ in /75 cm
Tire Type
Air Tire
Rim Type Rear
Aluminum
Rim Type Front
Aluminum
OEM Spec Rear
N/A
Outside Diameter Rear
15″ in / 38 cm x 6.3″ in / 16
cm
Tire Width Rear
6.3″ in / 16 cm
OEM Spec Front
N/A
Outside Diameter Front
13″ in / 33 cm x 4.5″ in /
11.5 cm
Tire Width Front
4.5″ in / 11.5 cm
Battery Type & Power
12V 75Ah x 2pcs
Brake System
Electromagnetic
Climbing Angle Maximum
Recommended
12 degree
Charger Type
8 Amp, Off Board120/240
Volt,50/60Hz
Charging Time
8-10hrs
Controller
S-DRIVE 200 Amp
*Driving Range
28 miles / 45 km
Load Capacity
350 lbs / 160 kgs
Motor & Drive Location
900 watts
*Speed Maximum
11.5 mph / 18.5 kph
Colors
Midnight Black
Tiller Type
D Type Handle
Throttle Control Type
Pot Meter
Anti-Tipper Wheels-Rear
Yes
The Vita Monster AL TERRAIN Four
Wheel Mobility Scoter
One Full
Year In Home Service Limited Warranty.
Your new
Vita Monster Scooter comes
with a full One Year In Home Service Warranty. Stop worrying
about who would repair your scooter or how you would get
your scooter to them. This warranty has you covered! We will
send a trained professional repair technician directly to
your home in the event your scooter should need repair. We
cover the entire United States. The map below indicates the
location of our service affiliates.
Personalize your new
Vita Monster Scooter. Its
Free & Easy,
Simply select letter of font style below you like and enter
it in the order form along with the name or text you would
like to use to personalize your new scooter.
A
B
C
D
E
F
G
H
I
J
We include a Oxygen
Tank Holder Free with the purchase of this scooter. This
Oxygen Tank Holder will hold most any size tank. The chart
shown on the left indicates with a red arrow all tank sizes
this tank holder will accommodate. Also included free are
all items listed below.
