The Vulcan
Scooter & Wheelchair Lift Weighs Only 22 Lbs With The
Ability To Lift A Portable Scooter Or Wheelchair
Weighting Up To 110 Lbs. The Vulcan Is The perfect
Solution For Those That Have the ability To Lift 22 Lbs
However are Unable To Lift Or Manage Their Portable
Scooter & Or Power Wheelchair. |
|
| The Vulcan Works
Well On Most Any Level Surface. It is Extremely Lightweight,
Very Strong & Easy To Use. |
 |
 |
| |
The Vulcan Is
Equipped With Two Very Unique Automatic Extending &
Automatic Retracting Stabilizing Wheels. As The Lift
Goes Up The Center Stabilizing Wheels Extend From Under
The Lift Making It Far More Stable Then It Would Be
Without This Feature. The Stabilizing Wheels Then
Automatically Retract Under The Lift As The Lift Is
Going Down. |
|
| Most Lifts Require
Extensive Installation And Then Limit Your Ability To Using
Only That Vehicle. With The Vulcan Their Is No Need To
Install It To The Vehicle. This Gives You The Flexibility To
Use Any Vehicle You Want And Not Limit You To Only One
Vehicle Like. |
 |
 |
| |
Easy To Use Up
& Down Two Button Handset With 6 Ft Cords Is Completely
Weather Proof. |
|
| The Vulcan Is
Designed To Run & Operate Utilizing The Battery Power From
Your Power Wheelchair Or Scooter. Simply Plug
it Into The Standard XLR Charging Port of Your Scooter Or
Power Wheelchair & The Vulcan Has Everything It Needs To
Rise & Lower.
A Optional Battery Is Available
For those That Would Prefer Or Individuals Lifting Manual
Wheelchairs. |
 |
 |
| xx |
The Vulcan Is a
Life Saver For A Large Number Of People That Have A
Scooter Or Power Wheelchair Weighing From 40 Lbs To 110
Lbs However Simply Can Not Lift It. Although They Are
Abel To Lift The 22 Lbs That The Vulcan Weighs
Giving Them Back The Freedom To Go Anywhere At Anytime
Without Relying On Other People. |
|
| |
|
|
Specifications For The Vulcan Scooter & Wheelchair
Lift |
| Total
Weight Of Lift: |
22 Lbs |
| Weight
Of Optional Battery: |
4 Lbs |
| Length: |
29.5 Inches |
| Width: |
18.8 Inches |
| Maximum
Lifting Height: |
29.9 Inches |
| Maximum
Lifting Capacity: |
110 LBS |
| Locking
Casters X 4: |
2 Inch |
|
Stabilizing Caster X 2: |
1.5 Inch |
| Package
Or Shipping Box: |
19.2 Inches X 9.8 Inches
X 29.2 Inches |
Motor:
|
4000(N) 24Volts |
| Input
Power: |
24 Volts |
| Power
Requirements: |
Will Work Using Power
from Any 24 V Scooter Or Wheelchair (With Standard XLR) |
|
Optional Battery: |
24 Volt 5 AH Lithium-ion |
|
Charger: |
24 2 AH Lithium-ion
(Included With Optional Battery) |
| Handset
(2 Button): |
Water Proof Handset With
6 Ft Cord |
|
Security Straps: |
4 Point Nylon Security
Straps With Buckles X 2 (4 parts) |
| Owners
Manual: |
|
| Video
#1: |
IMG_0937.MOV |
| Video
#2 |
IMG_0945.MOV |
| Video
#3 |
IMG_0946.MOV |
| Video
#4 |
IMG_0951.MOV |
|
| |
|
