VH-MP3 Piaggio MP3 Carrier

Versahaul MP3 Carrier

PRODUCT INFORMATION

Features

What's Included

Specifications

  • Fits any class III or IV hitch
  • Powder coat finish
  • Easily stores away
  • Boxed for UPS shipping
  • Reversible Rails



  • Anti-tilt lock bracket
  • 36 in. main tube
  • 3 wheel stops
  • Four retractable tie down bars
  • 3 ramps
  • 2 reflectors



  • Dimensions
  • Model Number: VH-MP3
  • Description: Moto Piaggio 3 Ramp Carrier
  • Approx. Shipping Wt.: 236 lbs.
  • Max Load: 600 lbs.
  • Length of ramp: 71 in.
  • Width of ramp: 7.625 in.
  • Pin to center of rail: 28.5 in.
  • VH-MP3 Instruction Booklet
LIMITATIONS

Carrier

Hitch

Vehicle

  • The VH-MP3 is designed to safely carry 600 lbs total but is limited to only 500 per rail.



  • Most Class III hitches are rated for 500 lbs.

  • Most Class IV hitches are rated for 1000 lbs.

  • Low hitch: The VersaHaul main tube extends out of the hitch at the same level. Hitches low to the ground will not work properly.

  • Recessed Hitches will shorten the length of the carrier tube.
  • Your hauling weight may be limited by your vehicle's capacity to carry a load and your vehicle's suspension. Please refer to information regarding your specific vehicle.

PICTURES

Click on the item to see a larger picture.

Protected by US Patent: US D554,041 S; 20070052206


Versa Haul VH-MP3 Piaggio MP3 Carrier

Versa Haul VH-MP3 Piaggio MP3 Carrier

Qty: Price: $1805.

Four Point Ratchet Tie Down System:
No Thank You.
Four Point Ratchet Tie Down System $34.88

Select Shipping:
Standard UPS Ground
FREE
Three Day Air $287.
